14. Standard setup manual
* Install this Equipment according to following format (Check the format for options or customized
specifications)
Model
Serial number
Installation
Date
Charged Personnel or
Company Name for
Installation
Installation
proved by
Judgment
№
Item
Implementation Method
Chapter No. & Reference page of
Instruction Manual
Judg-
ment
Specifications
1
Accessories
Check for number of accessories
Against to Accessories Column.
10. Specification
P.60
2
Installation
・Check room environment visually.
Caution: Take care for environment
・Make installation space.
2. Before operating the
Equipment
・ Precautions when
installing t･･･
P.6～9
Equipment Operation
1
Voltage of
Power Source
・Measure line voltage (power
distribution board of facilities,
receptacle, etc.) with voltmeter.
・Measure line voltage during
operation.
(Must meet required voltage.)
Caution: Check receptacle rating or
breaker on power switch
board rating to meet this
Equipment requirement.
2. Before operating the
Equipment
・Connect Power
Cord/Cable to
receptacle
or ･････
・Must connect
grounding
wire ･････
・Pay attention to･･･
10.Specification
・Power Supply
P.7
P.7
P.8
P.60
2
Operation
checking
・ Explain about names and
functions of each part
・ Execution of auto stop operation
Set temp.: 150℃ Setting
time :30 min
3. Names and
functions of each
part
・Main unit,
operational panel
4 Operating procedure
・Auto stop operation
P.10～11
P.21～23
Description
1
Operational
descriptions
Explain operations of each com-
ponent and handling precautions
according to Instruction Manual.
4. Operating procedure
・Prior confirmation
・Date & Time setting
5 Handling
precautions
・Warnings
・Cautions
13. List of dangerous
substances
13.1 Table of dangerous
P.13
P.14～49
P.50～53
P.69
2
Error Codes
Explain about error codes and
procedures for reset according to
Instruction Manual.
8. When a trouble
occurs
・Message error table
・Troubleshooting
P.56～57
P.58
3
Maintenance
and inspection
Explain operations of each
component according to Instruction
Manual.
6. Maintenance
method
・ Daily inspection/
maintenance
P.54
4
Completion of
installation
Entries
・ Fill in Installation Date and
Charged Personnel or Company
Name on OK and Service seal of
this Equipment.
・ Fill in necessary information to
Warranty Card and hand it over to
customer.
・ Explain how to contact with
service personnel.
9. After sales service
and warranty
・Request to repair parts
P.59
