3
VF2400
2. Installation
With UT device
Fig. 2-2
Refer to the instruction manual of the motor
for dimensions A, B, C, and D.
Section Y -Y
Section X - X
Operator
Table dimensions: 1200×595×40
center of pulley
3- φ 9.5 installing hole of motor
