1
VF2400
1
. Name of each part
Fig. 1-1
Thread guide plate
Handwheel
Seal plug(lubrication)
SP device
Oil sight window
Needle bar cover
Presser spring
regulator
Needle thread
take-up guard
Feed regulating
pushbutton
Side cover
Differential feed
graduation
Finger guard
Presser foot
Eye guard
Front cover
Supporting plate for
looper thread take-up
Oil sight gauge
Looper thread
take-up cover
Thread tension
spring cap
