Yamato VF2400 class User Manual

2
VF2400
2.1 semi-submerged type
2
. Installation
2.1.1 Table cutting diagram
Fig. 2-1
Standard
Table dimensions: 1200×595×40
Operator
center of pulley
Refer to the instruction manual of the motor for dimensions A, B, C, and D.
Section Y -Y (1/2)
Section X -X (1/2)
