3
.
Sewing speed and rotating direction of pulley
Table 4 shows maximum sewing speed and usual speed for
each model.
Run a new machine at speed about 15 - 20% lower than
maximum speed during the rst 200 hours (for about one
month) so that a machine can offer a long service life in
good condition.
The rotating directions of the machine pulley ① and the
handwheel ② are clockwise as shown in the gure.
Fig. 3-1
If rotated in reverse direction, oil cannot be supplied
properly. It can cause the damage to the machine.
Table 4
①
②
Model
Max. speed
(sti/min)
Usual
speed
(sti/min)
VF2400, 2500 (with spreader) 6500 6000
VF2403, 2503 (with spreader） 6000 5500
VF2404, 2504 (with spreader） 5000 4500
VF2411 (without spreader) 7000 6500
VF2530 (with spreader) 5500 5000
