Yamato VF2400 class User Manual

7
VF2400
2. Installation
Fig. 2-8
Install a machine correctly referring to Figs. 2-8 and 2-9.
Set the screws ② in the supporting board ① and cover the
screws ② with the rubber cushions ③ . Fix the the sup-
porting board ① to the machine table and install a machine
securely on the rubber cushions ③ .
2.2.2 Installation
Fig. 2-9
m a c h i n e
table
①
①
②
③
