Yanmar 3JH4CE - Air Heater (Optional)

12. Electrical System
189
12.8 Air Heater (Optional)
An air heater is available for warming intake air when starting in cold areas in winter. The air heater is
mounted to the intake manifold. The device is operated by the glow switch on the instrument panel.
Parts No. 129120-77501
Rated output 390W
Rated current 35.5A
Rated voltage DC11V
79
2-M6 x 1
terminal
4- 9
60
52
22
9
52.5
50
60 79
Relay
Air heater
Gasket
Intake manifold
Wire harness
