ENGINE
6-14
3TNV88F Service Manual
Measuring Instruments
9 V-block Locally available For measuring shaft bend
10 Torque wrench Locally available
For tightening nuts and bolts to the specified
torque
11 Feeler gauge Locally available
For measuring piston ring gaps, piston ring
clearance, and valve adjustment clearance
No. Instrument name Application Illustration
3TNV88F_SVM_A4.book 14 ページ ２０１２年７月２６日 木曜日 午後６時４分
To Next Page
