Chapter 9 E'Jectrical System
_3_. S_t_a_r_te_r_M_o_to_r __________________________ 3,4JH3(B)(C)E
(3) Inspection of the Center Bracket (P)
ll the diameter of the center bracket (P) is above the
limit then replace it.
Standard (New)
18 +0037
+0.012
(4) Inspection of the Pinion Shaft
mm
Limit {Used)
0.1
If the diameter of the Pinion Shatt is above the limit
then
replace it.
Standard (New)
6 7
+0.070
· +0.025
Printed in Japan
HfNSIH-H8009
mm
Limit (Used)
0.1
Fig. 33
Fig. 34
9-19
