™ PARTS NAME INDEX
PARTS NAME
PARTS No.
Fig
Ref.No.
PARTS NAME
PARTS No.
Hg
Ref.No.
RUBBER ELBOW
119175-49530
18
32- 1 S SEAT B, PLNGR. SPRING 119000-51181 41 16
RUBBER ELBOW
119175-49540
18
37- 1
S
SEAT, NOZZLE 119625-11880 9 42
RUBBER JOINT
119175-13800
18
36
S
SEAT, NOZZLE 119625-11880 10 41
RUBBER SEAT
119775-33620
22 9
S
SEAT, NOZZLE SPRING 114250-53130 46 7
RUBBER SEAT
119775-33650
31
7
S
SEAT, NOZZLE SPRING 114250-53130 46 23
SCREW
119175-42620
28
16
S
SEAT, NOZZLE SPRING 114250-53130 46 35
SCREW
127692-91410
65
30
S
SEAT, VALVE (EXHAUST 119100-11090 10 6
SCREW
127692-91410
66
35
S
SEAT, VALVE (INTAKE 119100-11080 10 5
SCREW
127692-91410
67 40
S
SENDA UNIT 119773-91600 63 21
SCREW
127692-91440
65 31
S
SENDA UNIT 119773-91650 62 35
SCREW
127692-91440
66 36
S
SENDA UNIT 119773-91700 62 36
SCREW
127692-91440
67
41
S
SENDER 121857-55730 51 5
SCREW
127692-91450
65
32
S
SENDER UNIT 119773-91500 62 16
SCREW
127692-91450
66
37
S
SENDER UNIT 119773-91501 62 16- 1
SCREW
127692-91450
67 42
S
SENDER UNIT 129574-91560 62 20
SCREW
XNB133206
15
24
S
SENDER UNIT 129574-91561 62 20- 1
SCREW
XNB133206
16
24
S
SENDER UNIT 129574-91570 62 21
SCREW
XNB133206
17
24
S
SENDER UNIT 144626-91570 62 17
SCREW 4
121254-77790
59 33
S
SENDER, OIL PRESSURE 124060-39451 62 10
SCREW A, GUIDE CAP
119000-51580
41 48
S
SENDER.OIL PRESSURE 124060-39452 62 10- 1
SCREW ASSY
XLI 5028001
60
20
S
SENSER 119773-91300 63 20
SCREW B, GUIDE CAP
119000-51590
41
49
S
SENSER 119773-91301 63 20- 1
SCREW KIT
119129-77930
61
19
S
SENSOR, TACHOMETER 128170-91160 62 13
SCREW KIT
X199903800X
39 8
S
SEPARATOR 120324-55750 52 1
SCREW KIT
X199903800X
40
8
S
SEPATATOR ASSY, WATER 121857-55800 51 2
SCREW M4
XNH163006
15
25
S
SETSCREW.OIL GALLERY 119000-01880 1 11
SCREW M4
XNH163006
16
25
S
SETTING, SAFETY SWIT. 177074-06300 62 28
SCREW M4
XNH163006
17 25
S
SHAFT 119175-42510 28 6
SCREW M6X 6
137600-53900
41
57
S
SHAFT 119593-61860 43 60
SCREW, VALVE
119000-11230
9 31
S
SHAFT ASSY, ARM 119100-11230 10 28
SCREW, VALVE
119000-11230
10
31
S
SHAFT ASSY, ARM 119173-11240 9 28
SEAL HTC95,115,12
124411-01780
7 3
S
SHAFT ASSY, GEAR 121254-77640 59 18
SEAL PLATE
XNN193012
15
10
S
SHAFT, GOV. LEVER 119000-61490 43 17
SEAL PLATE
XNN193012
16
10
S
SHAFT, IDLE GEAR 119000-25050 14 9
SEAL PLATE
XNN193012
17 10
S
SHAFT, IMPELLER
119171-42520 29 6
SEAL RING
XNN171006
15
6
S
SHIFTER
127495-61540 43 23
SEAL RING
XNN171006
16 6
S
SHIM PACK
114250-53400 46 16
SEAL RING
XNN171006
17 6
S
SHIM PACK 114250-53400 46 28
SEAL RING
XNN971007
15
7
S
SHIM PACK
114250-53400 46 40
SEAL RING
XNN971007
16 7
S
SHIM PACK
119000-61630 43 38
SEAL RING
XNN971007
17 7
S
SHIM SET, ADJUSTING
119000-51650 41 50
SEAL SCI 02004
120320-61540
43
34
S
SHIM SET, CAMSHAFT 119000-51450 41 40
SEAL, MECHANICAL
123472-42060
29
10
S
SIRENCER, TURBO
119195-18860 15 32
SEAL, MECHANICAL
X0520115000
28
14
S
SIRENCER, TURBO
119195-18860 16 30
SEAL, OIL
119129-77210
59 16
S
SIRENCER, TURBO
119195-18860 17 34
SEAL, OIL
121820-52040
44 4
S
SLEEVE ASSY
119187-61300 43 104
SEAL, OIL
121850-01800
2 6
S
SLEEVE, CONTROL
119000-51510 41 42
SEAL, VALVE STEM
119171-11150
9 19
S
SLEEVE, CONTROL
119000-51511 41 42- 1
SEAL, VALVE STEM
119171-11150
10
27
S
SNAP PIN 5
22360-050000 53 7
SEAL, VALVE STEM
121850-11150
9 18
S
SNAP PIN 6
22360-060000 53 20
SEAL, VALVE STEM
121850-11150 10
18
S
SNAP PIN JASO 5
22372-050000 43 144
SEAT A, PLNGR. SPRING
119000-51170 41 15
S
SOLENOID, FUEL CUT 119171-67200 42 16
