PRODUCT OVERVIEW
18
6LT Series Operation Manual
Q Operation of the Display’s Buttons
Buttons
Hot Key List
Figure 11
• Act on pop-up menu (MAIN MENU)
• Perform the function
 Up Arrow moves menu selection up
 Down Arrow moves menu selection down
 Left Arrow acts on current menu item
 Right Arrow acts on current menu item
OIL PRESSURE COOLANT TEMP
ENGINE SPEED
410
0 700
77
2500
40
05
14
23
120
Item Operation Indication
MAIN MENU Press the [ENTER] button. Display MAIN MENU.
MENU LAYER SKIP Hold the  button down for 1 second. Close MENU and return to the normal
screen.
ICON INFO Press the  button while the icon with a
detail information indication function is
displayed.
Display the related setting screen of the
relevant icon. If there are multiple items,
execute with the [ENTER] button after
selecting with the   buttons.
Adjusting Brightness Press the  button. Display the brightness adjustment screen
and adjust brightness with the   buttons.
(Manual dimmer mode only)
Switching Night Mode Press the  button. Switch to the night mode indication.
Setting Complete Hold the [ENTER] button down for 1 second
while the  icon is highlighted.
Close the setting screen and MENU and
return to the normal indication.
Switching Monitor
Display Indication
Press the  button. Switch to the monitor screen in the normal
indication. Send the screen in order with the
  buttons.
The monitor screen is fixed when there is no
operation with the   buttons for
5 seconds.
