A: From inside the Post Assemblies measure 4’ 11” to mark the centre of each Short Beam Assembly. (g. 16.1)
B: With all four assemblers place one Large Roof Panel Assembly with Roof to Beam Brackets just in front of the
Post Assemblies then raise it up so it is centred on the Long Beam Assembly. (g. 16.1)
Step 16: Attach Roof Panels to Frame
Part 1
Fig. 16.1
In front
of Post
Assembly
Long Beam
Assembly
Post
Assembly
Large Roof Panel
Assembly
Mark centre
location
Mark centre
location
x 3
Short Beam
Assembly
One assembler to support
roof panel(s) at all times until
secure
Short Beam
Assembly
Long Beam
Assembly
4’ 11”
