YASKAWA A1000 Installation Manual

30 YASKAWA ELECTRIC TOBP C730600 37B 1000-Series Option PG-X3 Installation Manual
8 Specifications
8 Specifications
Table 8 Option Specifications
Items Specifications
Model PG-X3
Compatible
Pulse Generators
Line driver
Single-channel (A pulse), two-channel (A, B pulse) or three-channel (A, B, Z (R)
pulse)
PG Wiring Length 100 m (328 ft.) maximum
PG Power Supply
Output voltage: 12 V ± 5% or 5.5 V ± 5%
Max. Output Current: 200 mA
Compatible Control
Modes
V/f with PG, Closed Loop Vector, Closed Loop Vector for PM motors
Maximum Input
Frequency
300 kHz
Pulse Monitor Output
Monitor for A channel, B channel, and Z pulse output
Matches RS-422 level
PG Disconnect
Detection
Software and hardware detection
Ambient Temperature -10 °C to +50 °C (14 °F to 122 °F)
Humidity 95% RH or lower with no condensation
Storage Temperature -20 °C to +60 °C (-4 °F to 140 °F) allowed for short-term transport of the product
Area of Use Indoor (free of corrosive gas, airborne particles, etc.)
Altitude 1000 m (3280 ft.) or lower

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
