5 Replace Cooling Fans and Circulation Fans
YASKAWA TOEP C730600 0FA Fan Replacement Procedure 11
2. Push the fan toward the bottom of the drive to push on the tabs at the bottom of the fan,
then pull the fan forward to remove it from the drive.
A - Circulation fan B - Tabs
Figure 5.10 Remove the Circulation Fan
■ Install a Circulation Fan
Note:
Use this procedure only when you use one of these drive models:
• 2024CVx, 2031CVx
• 4021CVx to 4034CVx
Reverse the removal procedure to install a circulation fan.
