■ Bottom Cover Wiring Space
Route the wiring between the cutouts of the covers as shown in Figure 15 when reattaching
the covers.
Note: Take proper precautions so that the front covers will easily fit back onto the unit.
Figure 15
Figure 15 Wiring Spaces
A – Wiring space for control circuit
terminals
C – Wiring space for ground terminals
B – Wiring space for LKEB braking
resistor unit
D – Wiring space for main circuit
terminals
A
Bottom View
BD
