Programming 67
 F5 DO-02, 08 Setup
 F5-01 DO-02 / DO-08 Channel 1 Output Selection
Setting Range: 0 to 38
Factory Default: 0
 F5-02 DO-02 / DO-08 Channel 2 Output Selection
Setting Range: 0 to 38
Factory Default: 1
 F5-03 DO-08 Channel 3 Output Selection
Setting Range: 0 to 38
Factory Default: 2
 F5-04 DO-08 Channel 4 Output Selection
Setting Range: 0 to 38
Factory Default: 4
 F5-05 DO-08 Channel 5 Output Selection
Setting Range: 0 to 38
Factory Default: 6
 F5-06 DO-08 Channel 6 Output Selection
Setting Range: 0 to 38
Factory Default: 37
 F5-07 DO-08 Channel 7 Output Selection
Setting Range: 0 to 38
Factory Default: F
 F5-08 DO-08 Channel 8 Output Selection
Setting Range: 0 to 38
Factory Default: F
These parameters set the digital output function number for channel 1 when digital output DO-02 or DO-08 option board is
used. See H2 parameter group for possible selections.
Parameters F5-01 and F5-02 set the digital output function number for channel 1 and 2, respectively when DO-02 or DO-08
digital output option board is used.
Parameters F5-03 to F5-08 set the digital output function number for channels 3 to 8 when DO-08 digital output option board
is used.
