YASKAWA CIMR-G5M

L1 (R)
Three phase Main circuit input power supply
L2 (S)
500 / 575 / 600V at 50 Hz / 60HZ
L3 (T)
T1 (U)
Three phase AC output to motor
T2 (V)
0V to max. input voltage level
T3 (W)
B1
B2
DB Resistor terminals (B1 & B2)
⊕ 1
⊕ 2
l 1 (r) Power for heat sink fan:
l 2 ( s ) l 1 to l 2 : 600 VAC
DB Units terminals (⊕ 1 & ) (C041 to C200 only)
DC Bus terminals (⊕ 1 & )
DC Reactor terminals (⊕ 1 & ⊕ 2)
DC Bus terminals (⊕ 1 & )
Ground terminal (100 ohms or less)
SECTION C. 600V
FUNCTION
New Model No.
51P51F - 50151F 50181F - 50221F 50301F - 51600F
TERMINAL
CIMR-G5M
Old Model No.
C003 - C022 C027 - C032 C041 - C200
GPD515C-
1-7
Table 1-2. Terminal Functions and Voltages of Main Circuit
