6 Parameter Table
EN 30 YASKAWA ELECTRIC TOEP C710606 15E - AC Drive V1000 - Quick Start Guide
E2-04 Motor Poles
Number of motor poles.
Automatically set by Auto-Tuning.
E2-05
Motor
Line-to-
Line
Resistance
Sets the phase-to-phase motor
resistance in ohms.
Automatically set by Auto-Tuning.
E2-06
Motor
Leakage
Inductance
Sets the voltage drop due to motor
leakage inductance as a percentage
of motor rated voltage.
Automatically set by Auto-Tuning.
Digital Input Settings
H1-01
to
H1-06
DI S1 to S6
Function
Selection
Selects the function of terminals
S1 to S6.
Major functions are listed at the end of the table.
Digital Output Settings
H2-01
DO
MA/MB
Function
Set the function for the relay
output MA-MB-MC.
H2-02
DO P1
Function
Sets the function for the
photocoupler output P1.
H2-03
DO P2
Function
Sets the function for the
photocoupler output P2.
Major functions are listed at the end of the table.
Analog Input Setting
H3-01
A1 Signal
Level Sel.
0:0 to +10 V (neg. input is zeroed)
1:0 to +10 V (bipolar input)
H3-02
A1
Function
Sel.
Assign a function to terminal A1.
H3-03 A1 Gain
Sets the input value in % at 10 V
analog input.
H3-04 A1 Bias
Sets the input value in % at 0 V
analog input.
H3-09
A2 Signal
Level
Selection
0:0 to +10 V (neg. input is zeroed)
1:0 to +10 V (bipolar input)
2:4 to 20 mA (9 bit input)
3:0 to 20 mA
H3-10
A2
Function
Sel.
Assign a function to terminal A2.
H3-11 A2 Gain
Sets the input value in % at
10 V/20 mA analog input.
Par. Name Description
H3-12 A2 Bias
Sets the input value in % at
0 V/0 mA/4 mA analog input.
Analog Input Setting
H4-01
AM
Monitor
Selection
Enter value equal to U1-
monitor values. Example: Enter
“103” for U1-03.
H4-02 AM Gain
Sets terminal AM output voltage
equal to 100% monitor value.
H4-02 AM Bias
Sets terminal AM output voltage
equal to 0% monitor value.
Pulse Input Setting (Free. ref. input)
H6-02
RP Input
Scaling
Sets the number of pulses (in Hz)
that is equal to 100% input value.
H6-03
Pulse Train
Input Gain
Sets the input value in % at pulse
input with H6-02 frequency.
H6-04
Pulse Train
Input Bias
Sets the input value in % at 0 Hz
pulse input frequency.
Pulse Output Setting
H6-06
MP Monitor
Sel.
Enter value equal to U-
monitor values. Example: Enter
“102” for U1-02.
H6-07
MP Monitor
Scaling
Sets the number of output pulses
when the monitor is 100% (in Hz).
Motor Overheat Protection
L1-01
Motor
Overload
Prot. Sel.
Sets the motor overload
protection.
0:Disabled
1:Standard fan cooled motor
2:Standard blower cooled motor
3:Vector motor
L1-02
Motor
Overload
Prot. Time
Sets the motor overload protection
time in min. Normally no change
is necessary.
Par. Name Description
