8 Instructions for UL and cUL
EN 40 YASKAWA ELECTRIC
TOEP C710606 15E - AC Drive V1000 - Quick Start Guide
Note: Use crimp insulated terminals or insulated tubing for wiring these connections. Wires should have a
continuous maximum allowable temperature of 75C 600 V UL approved vinyl sheathed insulation.
Ambient temperature should not exceed 30C.
Input Fuse Selection
Branch circuit protection shall be provided by any of the following:
• Non-time delay Class J, T, or CC fuses sized at 300% of the drive input rating
Note: Exceptional models are A6T6 with 2A0002, A6T15 with 2A0004 or 4A0004, A6T20 with 4A0005,
and A6T25 with 4A0007.
• Time delay Class J, T, or CC fuses sized at 175% of the drive input rating
• Time-delay Class RK5 fuses sized at 225% of the drive input rating
8 (8)
M4 8-4 1.2 to 1.5 (10.6 to 13.3)
M5 R8-5 2.0 to 2.5 (17.7 to 22.1)
M6 R8-6 5.4 to 6.0 (47.8 to 53.1)
M8 R8-8 9.9 to 11.0 (87.6 to 97.4)
14 (6)
M4 14-4 1.2 to 1.5 (10.6 to 13.3)
M5 R14-5 2.0 to 2.5 (17.7 to 22.1)
M6 R14-6 5.4 to 6.0 (47.8 to 53.1)
M8 R14-8 9.9 to 11.0 (87.6 to 97.4)
22 (4)
M6 R22-6 5.4 to 6.0 (47.8 to 53.1)
M8 R22-8 9.9 to 11.0 (87.6 to 97.4)
30/38 (3/2) M8 R38-8 9.9 to 11.0 (87.6 to 97.4)
Model
CIMR-V
Non-Time Delay
Class-T Fuse Type
(Manufacturer: Ferraz)
Fuse Ampere
Rating (A)
Fuse Type
(Manufacturer:
Bussmann)
500 Vac, 200 kAIR
Fuse Ampere
Rating (A)
Single-Phase 200 V Class
BA0001 A6T6 6 FWH-25A14F 25
BA0002 A6T10 10 FWH-25A14F 25
BA0003 A6T20 20 FWH-60B 60
BA0006 A6T40 40 FWH-80B 80
BA0010 A6T40 40 FWH-100B 100
BA0012 A6T50 50 FWH-125B 125
BA0018 A6T80 80 FWH-175B 175
Three-Phase 200 V Class
2A0001 A6T3 3 FWH-25A14F 25
2A0002 A6T6 6 FWH-25A14F 25
2A0004 A6T15 15 FWH-25A14F 25
Wire Gauge
mm
2
(AWG)
Terminal Screws
Crimp Terminal
Model Number
Tightening Torque
Nm (lbin.)
To Next Page
