Low Voltage Wiring for Control Circuit Terminals
Wire low voltage wires with NEC Class 1 circuit conductors; refer to national state or local
codes for wiring. Use a class 2 (UL listed) power supply for the control circuit terminal.
Table 2 Control Circuit Terminal Power Supply
2A0006 A6T20 20 FWH-25A14F 25
2A0010 A6T25 25 FWH-70B 70
2A0012 A6T25 25 FWH-70B 70
2A0020 A6T40 40 FWH-90B 90
2A0030
Not Available
FWH-100B 100
2A0040 FWH-200B 200
2A0056 FWH-200B 200
2A0069 FWH-200B 200
Three-Phase 400 V Class
4A0001 A6T3 3 FWH-40B 40
4A0002 A6T6 6 FWH-40B 40
4A0004 A6T15 15 FWH-50B 50
4A0005 A6T20 20 FWH-70B 70
4A0007 A6T25 25 FWH-70B 70
4A0009 A6T25 25 FWH-90B 90
4A0011 A6T30 30 FWH-90B 90
4A0018
Not Available
FWH-80B 80
4A0023 FWH-100B 100
4A0031 FWH-125B 125
4A0038 FWH-200B 200
Input / Output Terminal Signal Power Supply Specifications
Multi-function photocoupler outputs P1, P2, PC Requires class 2 power supply.
Multi-function digital inputs
S1, S2, S3, S4,
S5, S6, SC
Use the internal LVLC power supply of the drive.
Use class 2 for external power supply.
Multi function analog inputs +V, A1, A2, AC
Use the internal LVLC power supply of the drive.
Use class 2 for external power supply.
Pulse train input RP
Use the internal LVLC power supply of the drive.
Use class 2 for external power supply.
Pulse train output MP
Use the internal LVLC power supply of the drive.
Use class 2 for external power supply.
Model
CIMR-V
Non-Time Delay
Class-T Fuse Type
(Manufacturer: Ferraz)
Fuse Ampere
Rating (A)
Fuse Type
(Manufacturer:
Bussmann)
500 Vac, 200 kAIR
Fuse Ampere
Rating (A)
