3 Electrical Installation
YASKAWA ELECTRIC TOEP C710606 15E - AC Drive V1000 - Quick Start Guide EN 15
 Wiring Specification
 Main Circuit
Use the line filters listed in the table below when wiring the main circuit.
<1> Remove the jumper when installing an optional DC reactor.
<2> The MC on the input side of the main circuit should open when the thermal relay is triggered.
<3> Self-cooled motors do not require separate cooling fan motor wiring.
<4> Connected using sequence input signal (S1 to S6) from NPN transistor; Default: sink mode (0 V com).
<5> Use only a +24 V internal power supply in sinking mode; the source mode requires an external power supply.
<6> Monitor outputs work with devices such as analog frequency meters, ammeters, voltmeters and wattmeters; they
are not intended for use as a feedback-type of signal.
<7> Disconnect the wire jumper between HC, H1, and H2 when utilizing the safety input. The wire length for the Safe
Disable input should not exceed 30 m.
<8> Note that if the drive is set to trigger a fault output whenever the fault restart function is activated (L5-02 = 1), then
a sequence to interrupt power when a fault occurs will result in shutting off the power to the drive as the drive
attempts to restart itself. The default setting for L5-02 is 0 (fault output active during restart attempt).
Model
CIMR-V
EMC Filter Type
Recomm.
Motor cable
[mm²]
Main Circuit Terminal Sizes
Schaffner
R/L1, S/L2, T/L3, U/T1,
V/T2, W/T3, - , +1, +2
B1, B2 GND
BA0001 FS23638-10-07 2.5 M3.5 M3.5 M3.5
BA0002 FS23638-10-07 2.5 M3.5 M3.5 M3.5
BA0003 FS23638-10-07 2.5 M3.5 M3.5 M3.5
BA0006 FS23638-20-07 2.5 M4 M4 M4
BA0010 FS23638-20-07 2.5 M4 M4 M4
BA0012 FS23638-30-07 2.5 M4 M4 M4
BA0018 FS23638-40-07 2.5 M5 M5 M5
2A0001 FS23637-8-07 2.5 M3.5 M3.5 M3.5
2A0002 FS23637-8-07 2.5 M3.5 M3.5 M3.5
2A0004 FS23637-8-07 2.5 M3.5 M3.5 M3.5
2A0006 FS23637-8-07 2.5 M3.5 M3.5 M3.5
2A0010 FS23637-14-07 2.5 M4 M4 M4
2A0012 FS23637-14-07 2.5 M4 M4 M4
2A0020 FS23637-24-07 2.5 M4 M4 M4
2A0030 FS23637-52-07 6 M4 M4 M5
2A0040 FS23637-52-07 10 M4 M4 M5
2A0056 FS23637-68-07 16 M6 M5 M6
2A0069 FS23637-80-07 16 M8 M5 M6
4A0001 FS23639-5-07 2.5 M4 M4 M4
4A0002 FS23639-5-07 2.5 M4 M4 M4
4A0004 FS23639-5-07 2.5 M4 M4 M4
4A0005 FS23639-10-07 2.5 M4 M4 M4
4A0007 FS23639-10-07 2.5 M4 M4 M4
4A0009 FS23639-10-07 2.5 M4 M4 M4
4A0011 FS23639-15-07 2.5 M4 M4 M4
