3 Electrical Installation
EN 16 YASKAWA ELECTRIC
TOEP C710606 15E - AC Drive V1000 - Quick Start Guide
Input Fuse Selection
Use the fuses listed in the table on page 40 when wiring the main circuit.
Control Circuit
The control terminal board is equipped with screwless terminals. Always use wires within
the specification listed below. For safe wiring it is recommended to use solid wires or
flexible wires with ferrules. The stripping length respectively ferrule length should be 8 mm.
EMC Filter Installation
This drive has been tested in accordance with European standards IEC/EN 61800-3. In order
to comply to the EMC standards, wire the main circuit as described below.
1. Install an appropriate EMC noise filter to the input side. See the list above or refer to
the Technical Manual for details.
2. Place the drive and EMC noise filter in the same enclosure.
3. Use braided shield cable for the drive and motor wiring
4. Remove any paint or dirt from ground connections for minimal ground impedance
5. Install an AC reactor at drives smaller than 1 kW for compliance with the
IEC/EN 61000-3-2. Refer to the Technical Manual or contact your supplier for
details
4A0018 FS23639-30-07 2.5 M4 M4 M5
4A0023 FS23639-30-07 4 M4 M4 M5
4A0031 FS23639-50-07 6 M5 M5 M6
4A0038 FS23639-50-07 6 M5 M5 M6
Wire Type Wire size (mm
2
)
Solid 0.2 to 1.5
Flexible 0.2 to 1.0
Flexible with ferrule 0.25 to 0.5
Model
CIMR-V
EMC Filter Type
Recomm.
Motor cable
[mm²]
Main Circuit Terminal Sizes
Schaffner
R/L1, S/L2, T/L3, U/T1,
V/T2, W/T3, - , +1, +2
B1, B2 GND
