YASKAWA FP605

7 Electrical Installation
YASKAWA TOEPC7106171FD FP605 DRIVE INSTALLATION & PRIMARY OPERATION 33
Model Terminals
Recommended
Gauge
AWG, kcmil
Applicable Gauge
AWG, kcmil
(mm
2
)
*1
IP20 Applicable Gauge
*2
AWG, kcmil
(mm
2
)
*1
Wire Stripping
Length
*3
mm
Terminal Screw
Size and Shape
Tightening Torque
N∙m (lbf∙in)
2031
R/L1, S/L2, T/L3 8
14 - 8
(2.5 - 10)
- 10
M4
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 8
14 - 8
(2.5 - 10)
- 10
M4
1.5 - 1.7
(13.5 - 15)
-, +1 8
14 - 8
(2.5 - 10)
- 10
M4
1.5 - 1.7
(13.5 - 15)
10
14 - 8
(2.5 - 10)
- -
M5
2.0 - 2.5
(17.7 - 22.1)
2046
R/L1, S/L2, T/L3 8
14 - 4
(2.5 - 25)
- 18
M5
4.1 - 4.5
(36 - 40)
U/T1, V/T2, W/T3 6
14 - 4
(2.5 - 25)
- 18
M5
4.1 - 4.5
(36 - 40)
-, +1 6
14 - 4
(2.5 - 25)
- 18
M5
4.1 - 4.5
(36 - 40)
8
14 - 4
(2.5 - 25)
- -
M6
4.0 - 5.0
(35.4 - 44.3)
2059
R/L1, S/L2, T/L3 4
14 - 4
(2.5 - 25)
- 18
M5
4.1 - 4.5
(36 - 40)
U/T1, V/T2, W/T3 4
14 - 4
(2.5 - 25)
- 18
M5
4.1 - 4.5
(36 - 40)
-, +1 4
14 - 4
(2.5 - 25)
- 18
M5
4.1 - 4.5
(36 - 40)
6
14 - 4
(2.5 - 25)
- -
M6
4.0 - 5.0
(35.4 - 44.3)
2075
R/L1, S/L2, T/L3 4
8 - 2/0
(10 - 70)
- -
M8
5.4 - 6.0
(47.8 - 53.1)
U/T1, V/T2, W/T3 3 or 2
8 - 2/0
(10 - 70)
- -
M8
5.4 - 6.0
(47.8 - 53.1)
-, +1 2
8 - 2/0
(10 - 70)
- -
M8
5.4 - 6.0
(47.8 - 53.1)
6
8 - 2/0
(10 - 70)
- -
M8
9.0 - 11
(79.7 - 97.4)
2088
R/L1, S/L2, T/L3 3 or 2
8 - 2/0
(10 - 70)
- -
M8
5.4 - 6.0
(47.8 - 53.1)
U/T1, V/T2, W/T3 2
8 - 2/0
(10 - 70)
- -
M8
5.4 - 6.0
(47.8 - 53.1)
-, +1 1
8 - 2/0
(10 - 70)
- -
M8
5.4 - 6.0
(47.8 - 53.1)
6
8 - 2/0
(10 - 70)
- -
M8
9.0 - 11
(79.7 - 97.4)
2114
R/L1, S/L2, T/L3 1/0
8 - 2/0
(10 - 70)
- -
M8
5.4 - 6.0
(47.8 - 53.1)
U/T1, V/T2, W/T3 1/0
8 - 2/0
(10 - 70)
- -
M8
5.4 - 6.0
(47.8 - 53.1)
-, +1 2/0
8 - 2/0
(10 - 70)
- -
M8
5.4 - 6.0
(47.8 - 53.1)
6
8 - 2/0
(10 - 70)
- -
M8
9.0 - 11
(79.7 - 97.4)
