YASKAWA J1000 User Guide

Document Revision: v1.0.9
of
2 11
page
18805 Adams Ct., #110 ~ Morgan Hill, CA 95037, USA ~ +1-408.924.0808 ~ www.washlinksystems.com ~ support@washlinksystems.com
Document Title: Tech Guide ~ Yaskawa J1000/V1000/GA500 Basic User Guide
WASHLINK SYSTEMS
Yaskawa V1000 Basic User Guide
This document provides basic information for navigating and adjusting your Washlink Systems
supplied Yaskawa J1000/V1000/GA500 Variable Frequency Drive.
When emailing or calling for assistance, you must have the following information available:
Location Name: ______________________________
Contact Person: ______________________________
Contact Phone: ______________________________
VFD Model: ______________________________
Equipment connected: ______________________________
Distributor Name: ______________________________
COPYRIGHT
2022 Washlink Systems. All rights reserved.
THIS DOCUMENT IS THE EXCLUSIVE PROPERTY OF WASHLINK SYSTEMS AND IS PREPARED
ONLY FOR USE BY THE COMPANY PURCHASINGTHE EQUIPMENT. EDITING, COPYING,
DISTRIBUTING, AND/OR SELLING THIS DOCUMENT IS STRICTLY PROHIBITED WITHOUT PRIOR
WRITTEN CONSENT FROM WASHLINK SYSTEMS. WASHLINK SYSTEMS RESERVES THE RIGHT
TO EDIT THIS DOCUMENT IN ANY MANNER DEEMED NECESSARY, AT ANY TIME, AND WITHOUT
PRIOR NOTICE.

YASKAWA J1000 Specifications

General

Series	J1000
Voltage Class	200V, 400V
Frequency	50/60 Hz
Enclosure Rating	IP20
Enclosure Type	Open type
Voltage	200-240V, 380-480V
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault, Short Circuit
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Humidity	5-95% (non-condensing)
Enclosure	IP20
Input Voltage	200-240V, 380-480V
