v
162068-1CD
162068-1CD
MH-SERIES
POSITIONER
Definition of Terms Used Often in This Manual
The positioner usually consists of the controller, the Programming
Pendant, and supply cables.
In this manual, the equipment is designated as follows:
• Perform the following inspection procedures prior to conducting
positioner teaching. If problems are found, repair them immediately
and be sure that all other necessary processing has been
performed.
– Check for problems in positioner movement.
– Check for damage to insulation and sheathing of external wires.
• Always return the Programming Pendant to the hook on the cabinet
of the DX100 controller after use.
• The Programming Pendant can be damaged if it is left in the work
area, on the floor, or near fixtures.
• Read and understand the Explanation of Warning Labels in the
DX100 Controller Manual before operating the MH-SERIES
POSITIONER.
Equipment Manual Designation
DX100 controller DX100
DX100 Programming Pendant Programming Pendant
Cable between the positioner and the
controller
Power cables
