YASKAWA MOTOMAN-HP20D User Manual

6 Disassembly and Reassembly of Speed Reducer
6.3 Disassembly and Reassembly of U-Axis Speed Reducer
6-5
159281-1CD
HW1480357
HP20D
6.3 Disassembly and Reassembly of U-Axis Speed Reducer
• Refer to Fig. 6-3 “Disassembly and Reassembly of U-Axis Speed
Reducer”.
 Disassembly
1. Turn OFF the DX100 power supply, then drain grease.
2. Before removing the U-arm unit, support the U-arm unit with a chain
block, etc. to prevent it from falling.
3. Remove the hexagon socket head cap screws . Then, remove the
U-arm unit from the L-arm.
4. Remove the U-axis motor from the U-arm unit.
(Perform “Disassembly” in section 5.3 “Disassembly and Reassembly
of U-Axis Motor”.)
5. Remove the GT-SA bolts , then remove the speed reducer .
6. Remove the hexagon socket head cap screw , then remove the input
gear .
7. Remove the old sealing bond on the L-arm and the U-arm unit.
 Reassembly
1. Mount the input gear on the U-axis motor. (The input gear is
attached to the speed reducer . Thus, when replacing the speed
reducer , replace the input gear too.)
2. Apply Loctite 242 to the thread part of the hexagon socket head cap
screw . Then, tighten it with the tightening torque shown in Table 6-3
"U-Axis Speed Reducer Parts Checklist".
3. Apply ThreeBond 1206C on the matching surface between the speed
reducer and the U-arm unit. Then, mount the speed reducer on
the U-arm unit.
4. Tighten the GT-SA bolts with the tightening torque shown in Table
6-3 "U-Axis Speed Reducer Parts Checklist".
5. Mount the U-axis motor on the U-arm unit. (Perform “Reassembly” in
section 5.3 “Disassembly and Reassembly of U-Axis Motor”.)
6. Apply ThreeBond 1206C on the matching surface between the speed
reducer and the L-arm. Then, mount the U-arm unit with the speed
reducer on the L-arm.
7. Tighten the hexagon socket head cap screws with the tightening
torque shown in Table 6-3 "U-Axis Speed Reducer Parts Checklist".
For the screws marked with , apply ThreeBond 1206C on the thread
parts of them before tightening them.
8. Replenish grease (VIGO Grease RE No.0) through the grease inlet.
9. Turn ON the DX100 power supply.
3
2
1
4
5
5
5
1
1
5
4
1
1
2
1
1
3
56 of 96
