YASKAWA P1000 Safety Precautions

Drive Model Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
N·m (lb.in.)
4A0038
R/L1, S/L2, T/L3 6 8 to 6
M5
3.6 to 4.0
(31.8 to 35.4)
U/T1, V/T2, W/T3 8 8 to 6
⊖, ⊕1, ⊕2
– 6
B1, B2 – 10 to 8
2.7 to 3.0
(23.9 to 26.6)
6 10 to 6 M6
5.4 to 6.0
(47.8 to 53.1)
4A0044
R/L1, S/L2, T/L3 6 6 to 4
M6
5.4 to 6.0
(47.8 to 53.1)
U/T1, V/T2, W/T3 6 6 to 4
⊖, ⊕1, ⊕2
– 6 to 4
B1, B2 – 10 to 8 M5
2.7 to 3.0
(23.9 to 26.6)
6 8 to 6 M6
5.4 to 6.0
(47.8 to 53.1)
4A0058
R/L1, S/L2, T/L3 4 6 to 4
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2, W/T3 4 6 to 4
⊖, ⊕1
– 6 to 1
B1, B2 – 8 to 4
6 8 to 6
4A0072
R/L1, S/L2, T/L3 3 4 to 3
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2, W/T3 3 4 to 3
⊖, ⊕1
– 4 to 1
B1, B2 – 6 to 3
6 6
4A0088
R/L1, S/L2, T/L3 2 3 to 1/0
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2, W/T3 2 3 to 1/0
⊖, ⊕1
– 3 to 1/0
⊕3
– 6 to 1/0
4 6 to 4
4A0103
R/L1, S/L2, T/L3 1/0 2 to 1/0
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2, W/T3 1 2 to 1/0
⊖, ⊕1
– 3 to 1/0
⊕3
– 4 to 1/0
4 6 to 4
4A0139
R/L1, S/L2, T/L3 3/0 1/0 to 4/0
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 2/0 1/0 to 4/0
⊖, ⊕1
– 1/0 to 4/0
⊕3
– 3 to 4/0
4 4
4A0165
R/L1, S/L2, T/L3 4/0 3/0 to 4/0
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 4/0 3/0 to 4/0
⊖, ⊕1
– 1 to 4/0
⊕3
– 1/0 to 4/0
4 4 to 2
4A0208
R/L1, S/L2, T/L3 300 2 to 300
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 300 2 to 300
⊖, ⊕1
– 1 to 250
⊕3
– 3 to 3/0
4 4 to 300
i.3 Electrical Installation Safety
YASKAWA ELECTRIC TOEP YAIP1U 03B YASKAWA AC Drive – P1000 Safety Precautions
27

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
