10.1 Corresponding SERVOPACK and SigmaWin+ Function Names
10.1.2 Corresponding SERVOPACK Monitor Display Function Names
10-5
10
Appendices
*1. You can use Un010 to monitor the upper limit setting for the maximum motor speed or the upper limit setting for
the encoder output resolution.
You can monitor the upper limit of the encoder output resolution setting (Pn281) for the current maximum motor
speed setting (Pn385), or you can monitor the upper limit of the maximum motor speed setting for the current
encoder output resolution setting.
Select which signal to monitor with Pn080 = n.X (Calculation Method for Maximum Speed or Divided Out-
put Pulses).
• If Pn080 = n.0, the encoder output resolution (Pn281) that can be set is displayed.
• If Pn080 = n.1, the maximum motor speed (Pn385) that can be set is displayed in mm/s.
*2. This applies to the following motors. The display will show 0 for all other models.
SGM7J, SGM7A, SGM7P, SGM7G, and SGMCV
Status
Monitor
Polarity Sensor Signal Monitor Un011 Polarity Sensor Signal Monitor
Active Gain Monitor Un014
Effective Gain Monitor (gain settings 1 = 1, gain
settings 2 = 2)
Safety I/O Signal Monitor Un015 Safety I/O Signal Monitor
Input
Signal
Monitor
Input Signal Monitor Un005 Input Signal Monitor
Output
Signal
Monitor
Output Signal Monitor Un006 Output Signal Monitor
Service
Life
Monitor
Installation Environment Monitor −
SERVOPACK
Un025
SERVOPACK Installation Environment Monitor
[%]
Installation Environment Monitor −
Servomotor
*2
Un026
*2
Servomotor Installation Environment Monitor
[%]
Service Life Prediction Monitor −
Built-in Fan
Un027 Built-in Fan Remaining Life Ratio [%]
Service Life Prediction Monitor −
Capacitor
Un028 Capacitor Remaining Life Ratio [%]
Service Life Prediction Monitor −
Surge Prevention Circuit
Un029
Surge Prevention Circuit Remaining Life Ratio
[%]
Service Life Prediction Monitor −
Dynamic Brake Circuit
Un02A Dynamic Brake Circuit Remaining Life Ratio [%]
Product
Informa-
tion
Motor − Resolution
Un084
Linear Encoder Pitch (Scale pitch = Un084 ×
10
Un085
[pm])
Un085
Linear Encoder Pitch Exponent (Scale pitch =
Un084 × 10
Un085
[pm])
–
– Un020
Rated Motor Speed [min
-1
]
– Un021
Maximum Motor Speed [min
-1
]
Continued from previous page.
SigmaWin+ SERVOPACK
Menu Bar
Button
Name [Unit] Un No. Name [Unit]
