Standard Operator Panel
Display
To Access & Change Paramaters
Press the or button until the screen showes Parameter Setting mode.
Press the button, display will now show Parameter A1-02 with the “A” flashing
ENTER
Press the or or to get to the parameter you want to adjust, then press
ENTER
RESET
You will now see the current setting for the selected parameter, left digit will flashing
Press the or or to change the parameter, then press
ENTER
RESET
With the VFD powered on and the motor not running;
You will now see the next parameter with the left digit flashing
1.
2.
3.
4.
5.
6.
If you want to adjust more parameters, go to step 3.7.
If you are done, press until you get back to the screen8.
ESC
Press the or button until the screen shows (motor speed in Hz).
9.
