Document Title: Tech Guide ~ Yaskawa V1000 Basic User Guide
Common Drive Monitors
Note: these are basic tips, refer to the technical manual for more information
U1-01 Frequency Reference Monitors the frequency
U1-02 Output Frequency Displays the output frequency. Display units are determined by o1-03.
U1-03 Output Current Displays the output current.
U1-04 Control Mode Control method set in A1-02.
U1-05 Motor Speed Displays the motor speed feedback. Display units are determined by o1-03.
U1-06 Output Voltage Reference Displays the output voltage.
U1-07 DC Bus Voltage Displays the DC bus voltage.
U1-08 Output Power Displays the output voltage (this value is determined internally).
U1-13 Terminal A1 Input Level Displays analog input A1 level: 100% when input is 10 V.
U1-14 Terminal A2 Input Level Displays analog input A1 level: 100% when input is 10 V.
U3-01 Most Recent Fault Displays the most recent fault.
U3-02 2nd Most Recent Fault Displays the second most recent fault.
U3-03 3rd Most Recent Fault Displays the third most recent fault.
U3-04 4th Most Recent Fault Displays the fourth most recent fault.
U3-05 5th Most Recent Fault Displays the fifth most recent fault.
U3-06 6th Most Recent Fault Displays the sixth most recent fault.
U3-07 7th Most Recent Fault Displays the seventh most recent fault.
U3-08 8th Most Recent Fault Displays the eighth most recent fault.
U3-09 9th Most Recent Fault Displays the ninth most recent fault.
U3-10 10th Most Recent Fault Displays the tenth most recent fault.
U4-01 Accumulated Operation Time Displays the cumulative operation time of the drive.
U4-02 Number of Run Commands Displays the number of times the run command is entered.
