u
Drive Model Number Definition
CIMR
-
Z U 2 A
0024 F
A A
Drive
Z1000
Series
No.
Enclosure Type
Design
Revision
Order
No.
Customized
Specifications
A Standard model
No.
Region
Code
U USA
IP00/
Open-Type
F
IP20/NEMA 1,
UL type 1
A
No. Voltage Class
No.
Environmental
Refer to the following tables
Specification
A Standard
3-phase, 200-240 Vac
2
3-phase, 380-480 Vac
4
Figure i.4 Drive Model Number Definition
n
Three-Phase 200 V Class
Table i.1 Model Number and Specifications (200 V Class)
Drive Model
Max Motor Capacity
kW (HP)
Rated Output
Current A
2A0011 2.2 (3) 10.6
2A0017 3.7 (5) 16.7
2A0024 5.5 (7.5) 24.2
2A0031 7.5 (10) 30.8
2A0046 11 (15) 46.2
2A0059 15 (20) 59.4
2A0075 18.5 (25) 74.8
2A0088 22 (30) 88
Drive Model
Max Motor Capacity
kW (HP)
Rated Output
Current A
2A0114 30 (40) 114
2A0143 37 (50) 143
2A0169 45 (60) 169
2A0211 55 (75) 211
2A0273 75 (100) 273
2A0343 90 (125) 343
2A0396 110 (150) 396
n
Three-Phase 400 V Class
Table i.2 Model Number and Specifications (400 V Class)
Drive Model
Max Motor Capacity kW (HP)
Rated Output
Current A
Input Voltage <
460 V
Input Voltage ≥
460 V
4A0005 1.5 (2) 2.2 (3) 4.8
4A0008 3.0 (4) 3.7 (5) 7.6
4A0011 4.0 (5) 5.5 (7.5) 11
4A0014 5.5 (7.5) 7.5 (10) 14
4A0021 7.5 (10) 11 (15) 21
4A0027 11 (15) 15 (20) 27
4A0034 15 (20) 18.5 (25) 34
4A0040 18.5 (25) 22 (30) 40
4A0052 22 (30) 30 (40) 52
4A0065 30 (40) 37 (50) 65
4A0077 37 (50) 45 (60) 77
Drive Model
Max Motor Capacity kW (HP)
Rated Output
Current A
Input Voltage <
460 V
Input Voltage ≥
460 V
4A0096 45 (60) 55 (75) 96
4A0124 55 (75) 75 (100) 124
4A0156 75 (100) 90 (125) 156
4A0180 90 (125) 110 (150) 180
4A0240 110 (150) 150 (200) 240
4A0302 160 (220) 185 (250) 302
4A0361 185 (250) 220 (300) 361
4A0414 220 (300) 260 (350) 414
4A0480 250 (340) 300 (400) 480
4A0590 300 (400) 370 (500) 590
i.2 Receiving
12
YASKAWA ELECTRIC TOEP C710616 54A YASKAWA AC Drive - Z1000 Quick Start Guide
