Yealink SIP-T19P User Manual

User Guide for the SIP-T19P IP Phone
90
6. Click Confirm to accept the change.
Note
Music on hold (MoH) is the business practice of playing recorded music to fill the silence
that would be heard by the party placed on hold. To use this feature, you should specify
a SIP URI pointing to a MoH server account. When a call is placed on hold, the phone
will send a SIP INVITE message to the MoH server account. The MoH server account
automatically answers to the SIP INVITE messages and immediately plays audio from
some source located anywhere (LAN, Internet) to the held party. Contact your system
administrator for the SIP URI.
To configure MoH server via web user interface:
1. Click on Account->Advanced.
2. Enter the SIP URI (e.g., sip:moh@sip.com) in the Music Server URI field.
3. Click Confirm to accept the change.
The priorities of listening addresses are predefined: 1 with the highest priority, 10 with the
lowest.
The phone plays a warning tone when receiving incoming multicast paging calls.
The phone will not receive a new incoming multicast paging call when there are two
calls on the phone.
Multicast listening addresses is configurable via web user interface only.

Yealink SIP-T19P Specifications

General

Speakerphone	Yes
Voice codecs	CNG, G.711, G.723, G.726, G.729ab, VAD
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Front camera	No
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	1
Security algorithms	802.1x RADIUS, AES, HTTPS
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3u
Supported network protocols	IPv6
Ethernet LAN (RJ-45) ports	2
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	185 mm
Height	143 mm
