placed in the parenthesis. The number directs to the right parenthesis when
there are more than one. Example:
A replace rule configuration: Prefix: "9([5-7]) (.)", Replace: "5$2". When you
enter "96123" to dial out on your phone, the number will be replaced as "5123"
and then dialed out. “$2” means the characters in the second parenthesis,
that is, “123”.
You can configure one or more replace rules (up to 100) to remove the specified string
and replace it with another string. You can configure a pattern with wildcards (refer to
the expression syntax in the table above), so that any string that matches the pattern
will be replaced. This feature is convenient for you to dial out a long number. For
example, a replace rule is configured as “Prefix: 1” and “Replace: 1234567”. When
trying to dial out the number “1234567”, you just need to enter “1” on the phone and
then press the Send soft key.
To add a replace rule via web user interface:
1. Click on Settings->Dial Plan->Replace Rule.
2. Enter the string (e.g., 1) in the Prefix field.
3. Enter the string (e.g., 1234) in the Replace field.
4. Enter the desired line ID in the Account field or leave it blank.
5. Click Add to add the replace rule.

Yealink SIP-T21P Specifications

General

Display	132 x 64-pixel graphical LCD
Network	10/100 Mbps Ethernet
SIP Accounts	2
Wall Mountable	Yes
Audio Features	HD Voice
Protocols	SIP v1 (RFC2543), v2 (RFC3261)
Voice Codecs	G.711(A/μ), G.729AB, G.726, G.722
Phonebook	1000 entries
Call Features	Call hold, call waiting, call transfer, call forward, 3-way conferencing
Security	SRTP, TLS, 802.1x, HTTPS
Ethernet Ports	2 x RJ45 10/100 Mbps
Power Supply	Power over Ethernet (PoE) or optional power adapter
Operating Humidity	10% to 90% (non-condensing)
Languages	Supports multiple languages
PoE	Yes (802.3af)
Operating Temperature	-10°C to 50°C
