Yealink SIP-T23G User Manual

User Guide for the SIP-T23P/G IP Phone
80
You can configure one or more dial-now rules (up to 100) on your phone. When the
dialed number matches the dial-now string, the number will be dialed out automatically.
For example, a dial-now rule is configured as "1xx", any entered three-digit string
beginning with 1 will then be dialed out automatically on the phone.
To add a dial-now rule via web user interface:
1. Click on Settings->Dial Plan->Dial-now.
2. Enter the desired value (e.g., 1xx) in the Rule field.
3. Enter the desired line ID in the Account field or leave it blank.
For more information on the valid values for the Account field, refer to Replace Rule
on page 78.
4. Click Add to add the dial-now rule.
When you enter the number “123” using the keypad, the phone will dial out “123”
automatically without pressing any key.
Note
Delay Time for Dial-now Rule
You can configure the delay time for dial-now rules. That is, you can configure your
phone to automatically dial out the phone number which matches a dial-now rule, after
the designated delay time.
You can also edit or delete the dial-now rule, refer to Replace Rule on page 78 for more
information.
Dial-now rule is configurable via web user interface only.

Yealink SIP-T23G Specifications

General

Backlight	Yes
Voice codecs	G.711a, G.722.2, G.726, G.729ab, iLBC
Volume control	Digital
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Silver
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.56 W
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	209 mm
Height	150 mm
