Yealink SIP-T29G User Manual

Customizing Your Phone
51
To configure the SNTP settings via phone user interface:
1. Press Menu->Basic->Time & Date->General->SNTP Settings.
2. Press or , or the Switch soft key to select the time zone that applies to your area
from the Time Zone field.
The default time zone is “+8”.
3. Enter the domain name or IP address of SNTP server in the NTP Server1 and NTP Server2
field respectively.
4. Press or , or the Switch soft key to select the desired value from the Daylight
Saving field.
5. Press or , or the Switch soft key to select the desired time zone name from the
Location field.
The default time zone name is “China(Beijing)”.
6. Press the Save soft key to accept the change or the Back soft key to cancel.
Note
To configure the time and date manually via phone user interface:
1. Press Menu->Basic->Time & Date->General->Manual Settings.
2. Enter the specific date and time.
3. Press the Save soft key to accept the change.
The time and date displayed on the LCD screen will change accordingly.
Please refer to Appendix A – Time Zones for the list of available time zones on the IP phone.

Yealink SIP-T29G Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.723, G.726, G.729ab, iLBC
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Lines quantity	10 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Power over Ethernet (PoE)	-
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800
Volume control	Buttons

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
