Yealink SIP-T29G User Manual

Basic Call Features
135
Call Forward
You can configure your phone to forward incoming calls to another party (static forwarding).
You can also forward calls while your phone is ringing (dynamic forwarding).
Note
Static Forwarding
Three types of static forwarding:
 Always Forward: Incoming calls are immediately forwarded.
 Busy Forward: Incoming calls are immediately forwarded if the phone is busy.
 No Answer Forward: Incoming calls are forwarded if not answered after a period of time.
You can enable/disable call forward for the phone system, or you can customize call forward for
each or all accounts. Two call forward modes:
 Phone (default): Call forward is effective for the phone system.
 Custom: Call forward can be configured for each or all accounts.
To configure the call forward mode via web user interface:
1. Click on Features->Forward&DND.
2. In the Forward block, mark the desired radio box in the Mode field.
When the phone forwards a call, a prompt window will pop up by default. If you want to disable
the feature, contact your system administrator for more information.

Yealink SIP-T29G Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.723, G.726, G.729ab, iLBC
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Lines quantity	10 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Power over Ethernet (PoE)	-
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800
Volume control	Buttons

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
