Yealink SIP-T29G User Manual

User Guide for the SIP-T29G IP Phone
136
3. Click Confirm to accept the change.
Note
To enable call forward in phone mode:
1. Press Menu->Features->Call Forward.
2. Press or to select the desired forwarding type, and then press the Enter soft key.
3. Depending on your selection:
a) If you select Always Forward:
1) Press or , or the Switch soft key to select Enabled from the Always
Forward field.
2) Enter the destination number you want to forward all incoming calls to in the
Forward to field.
3) (Optional.) Enter the always forward on code or off code respectively in the On
Code or Off Code field.
b) If you select Busy Forward:
1) Press or , or the Switch soft key to select Enabled from the Busy
Forward field.
2) Enter the destination number you want to forward incoming calls to when the
phone is busy in the Forward to field.
3) (Optional.) Enter the busy forward on code or off code respectively in the On
Code or Off Code field.
Call forward mode is configurable via web user interface only.

Yealink SIP-T29G Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.723, G.726, G.729ab, iLBC
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Lines quantity	10 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Power over Ethernet (PoE)	-
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800
Volume control	Buttons

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
