5.2.2.2.1 Create or Modify Device Profile Type
This section identifies the BroadWorks device profile type settings relevant to Device
Management for the Yealink T4x IP Phone.
Browse to System → Resources → Identity/Device Profile Types and perform a search to
find the Yealink device profile type(s) created in section 3.1 BroadWorks Device Profile
Type Configuration or add the device profile type for each model using the settings from
section 3.1 BroadWorks Device Profile Type Configuration if they do not exist.
Configure the device profile type Signaling Address Type, Standard and Advanced options
settings to match the settings in section 3.1 BroadWorks Device Profile Type
Configuration.
Configure the device profile type Device Management options as shown in section 5.2.2.1
Configuration Method 1: Import.
The following subsections identify the required settings specific to Device Management.
5.2.2.2.2 Define Device Profile Type Files
This section describes the BroadWorks Device Management configuration necessary to
identify the configuration files and other files that the Yealink T4x IP Phone downloads.
Configuration templates, firmware, and other files the T4x IP Phone uses must be
uploaded to BroadWorks. Download the Yealink T4x IP Phone CPE kit from BroadSoft
Xchange at xchange.broadsoft.com. Extract the configuration files from the Configuration
Files folder of CPE kit. Obtain the firmware files directly from Yealink.
The following table identifies the Yealink T4x IP Phone configuration files distributed with
the firmware version73 CPE kit.
File Name CPE Kit Template File Name File Type Description
System-
level,
Device-
specific,
Static, Time
Zone Alias
Examples
BWMACADDRESS.cfg %BWMACADDRESS%-
T4x.cfg
Device-
specific
This file contains device-specific
parameters that the phone has to
load.
y0000000000xx.cfg
T40P: xx=54
T40G: xx=76
T41P: xx=36
T42G: xx=29
T46G: xx=28
T48G: xx=35
T41S: xx=68
T42S: xx=67
T46S: xx=66
T48S: xx=65
T49G: xx=51
y0000000000xx.cfg
T40P: xx=54
T40G: xx=76
T41P: xx=36
T42G: xx=29
T46G: xx=28
T48G: xx=35
T41S: xx=68
T42S: xx=67
T46S: xx=66
T48S: xx=65
T49G: xx=51
System-
level
This file contains system level
parameters that the phone has to
load.

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
