Using TLS
NOTE: If you choose to use HTTPS as a protocol for registering your phone:
Open a new browser window and enter your phone IP address, e.g. http://192.168.1.22.
Enter username and password and press Confirm button. NOTE: Factory default login
details are username: admin and password: admin.
Click on Security tab and go to Trusted certificates and disable the option Only Accept
Trusted Certificates.
DNS SRV
DNS SRV
This chapter describes how to use a DNS SRV record which specifies the location of the
PBXware. NOTE: Your DNS Server needs to be configured correctly for this to work. Bicom
Systems can provide service to set up this for you.
Check if the DNS SRV is enabled in your PBXware
Contact your PBXware administrator to find out if the DNS SRV is enabled in your PBXware,
or if you have access to the PBXware you can check this yourself.
Open a new browser window and enter the IP address in order to access the PBXware web
administration login screen. Example: http://192.168.1.10.
Login to PBXware with your e-mail address and password.
Navigate to Settings ---> Servers. Click on the server corresponding edit button. NOTE:
On MT, navigate to Settings ---> Tenants ---> Master Tenant.
In Auto Provisioning group, make sure Use DNS SRV when possible: is set to Yes. If it is
set to No or N/A, set to Yes and click on the Save button. NOTE: You must re-save all your
extensions configured for Auto Provisioning.
Login to phone web administration interface
If there is no DHCP in your network, you can still auto provision your Yealink phone. Please
refer to your Yealink phone model User Guide for instruction about setting static IP address.
After you configure your Yealink phone to use a static IP address, continue with the following
steps.
Open a new browser window and enter your phone IP address in order to access the phone
web administration interface login screen. Example: http://192.168.1.22
Login to phone web administration interface with your username and password. Please note,
factory default login details are username: admin and password: admin.
Click on Upgrade tab.
Click Advanced tab.
