Yealink T46S Quick Reference User Guide

To disconnect wireless network via phone user interface:
1. Press Menu > Basic > Wi-Fi
> X Available Network(s) (X represents the number of available
networks)
2. Select the connected wireless network, and then press the Disconnect soft key.
The wireless network is disconnected. You can press the Connect soft key to connect again
Yealink T46S Wireless Settings
Disconnecting the Wireless Network Connection
Deactivating the Wi-Fi Mode
To deactivate the Wi-Fi mode via phone user interface:
1. Press Menu > Basic > Wi-Fi
2. Tap Press or , or the Switch soft key to select Off from the Wi-Fi field
3. Press the Save soft key to accept the changes
4. The Wi-Fi icon disappears from the touch screen
Note: Wi-Fi is configurable via web user interface at the path Network->Wi-Fi.
Optus Loop – Wireless Settings Yealink T46S QRG
7

Yealink T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
