NeoGate User Manual
www.yeastar.com 25
·Description
Simple description for this rule. eg: Accept the specific host to access the web
interface for configuration.
·Protocol
The protocols of this rule.
·Port
Initial port should be on the left and end port should be on the right.
The end port must be equal to or greater than start port.
·IP
The IP address for this rule. The format of IP address is: IP/mask
Ex: 192.168.5.100/255.255.255.255 for ip 192.168.5.100
Ex: 216.207.245.47/255.255.255.255 for ip 216.207.245.47
Ex:192.168.5.0/255.255.255.0 for ip from 192.168.5.0 to 192.168.5.255.
·MAC Address
The format of MAC Address is XX:XX:XX:XX:XX:XX, X means 0~9 or A~F in hex,
the A~F are not case sensitive.
·Action
Accept: Accept the access from remote hosts.
Drop: Drop the access from remote hosts.
Ignore: Ignore the access.
Figure 3-17
3) Auto Defense
·Port
Auto defense port, e.g.: 8022.
