NeoGate User Manual
www.yeastar.com 6
2. System set up
2.1 SIM Card Placement
Lift off the SIM card holder on the backside, insert the SIM card and replace
the holder, securing the latch.
Note1: Remember to set call forwarding, call barring, preferential
network(s), SMS centre and similar provider and SIM card services in your
mobile phone before inserting the SIM card in NeoGate.
Note2: Disconnect NeoGate from the power supply before inserting the SIM
cards.
2.2 Antenna Connection
NeoGate is equipped with two antenna connector for all the GSM modules.
The external antenna should always be installed vertically on a site with a
good wireless signal.
2.3 Ethernet Line Connection
NeoGate provides two 10/100M Ethernet ports with RJ45 interface and LED
indicator. Plug Ethernet line into NeoGate’s Ethernet port, and then
connect the other end of the Ethernet line with a hub, switch, router, LAN or
WAN. Once connected, check the status of the LED indicator. A yellow LED
indicates the port is in the connection process, and a green LED indicates the
port is properly connected.
2.4 Power Supply Connection
NeoGate utilizes the high-performance switch power, which supply the
enough voltage and electrical energy that required by NeoGate system.
AC Input: 100~240V
DC Output: 12V,1A
Please follow the steps below to connect the NeoGate unit to a power outlet:
