TA1600/2400/3200 User Manual
70/87
2) Common Rules
There is no default rule; you can create one as required.
Figure 10-8 Common Rules
Table 10-3 Description of Common Rules
A name for this rule, e.g. “HTTP”.
Simple description for this rule. E.g. accept the specific host to
access the Web interface for configuration.
The protocols for this rule.
Initial port should be on the left and end port should be on the right.
The end port must be equal to or greater than start port.
The IP address for this rule. The format of IP address is: IP/mask
E.g. 192.168.5.100/255.255.255.255 for IP 192.168.5.100
E.g. 192.168.5.0/255.255.255.0 for IP from 192.168.5.0to
192.168.5.255.
The format of MAC Address is XX:XX:XX:XX:XX:XX, X means 0~9
or A~F in hex, the A~F are not case sensitive.
Accept: Accept the access from remote hosts.
