IM 01E20D01-01E
6-46
6. OUTLINE
Flameproof Packing Adapter for TIIS Flameproof Type (Optional code G12 or G11)
T1
T2
L
18(0.71)
G
F
D
C
16.5(0.65)
*Packing
(Choose from the table below
depend on cable outside diameter)
Unit : mm
(Approx. inch)
F43.EPS
Adapter body(M. Screw)
Packing case
Hexagon socket set screw
O-Ring
Packing *
O-Ring
O-Ring
Washer
Union nut
Packing gland
Clamp ring
Clamp nut
O-Ring
B.coupling
Cable(user's scope)
Hexagon socket set screw
0.26
(0.57)
ø8.0 to ø10.0 (0.31 to 0.39)
ø10.0 to ø12.0 (0.39 to 0.47)
16 8-10
16 10-12
Identification
mark
Weight
kg
(lb)
Packing diameter
Cable outer diameter
T1 T2 C D
L
DimensionNominal diameter
G 1/2 G 1/2
35
(1.38)
39
(1.54)
94.5
(3.72)
ø10.0(0.39)
ø12.0(0.47)
ø20.0
(0.79)
F
G
T31.EPS
*: G 11: 1 unit
G 12: 2 units
Parts No.
G9601AM*
Unless otherwise specified, difference in the dimensions are refer to the following table.
Above Equal or below Above Equal or below
Category of basic dimension
Category of basic dimension
Tolerance Tolerance
3 (0.12)
6 (0.24)
10 (0.39)
18 (0.71)
30 (1.18)
50 (1.97)
80 (3.15)
120 (4.72)
180 (7.09)
250 (9.84)
315 (12.40)
400 (15.75)
3 (0.12)
6 (0.24)
10 (0.39)
18 (0.71)
30 (1.18)
50 (1.97)
80 (3.15)
120 (4.72)
180 (7.09)
250 (9.84)
315 (12.40)
400 (15.75)
500 (19.69)
0.7 (0.03)
0.9 (0.04)
1.1 (0.04)
1.35 (0.05)
1.65 (0.06)
1.95 (0.08)
2.3 (0.09)
2.7 (0.11)
3.15 (0.12)
3.6 (0.14)
4.05 (0.16)
4.45 (0.18)
4.85 (0.19)
500 (19.69)
630 (24.80)
800 (31.50)
1000 (39.37)
1250 (49.21)
1600 (62.99)
2000 (78.74)
2500 (98.43)
630 (24.80)
800 (31.50)
1000 (39.37)
1250 (49.21)
1600 (62.99)
2000 (78.74)
2500 (98.43)
3150 (124.02)
5.5 (0.22)
6.25 (0.25)
7.0 (0.28)
8.25 (0.32)
9.75 (0.38)
11.5 (0.45)
14.0 (0.55)
16.5 (0.65)
Remarks: The numeric is based on criteria of tolerance class IT18 in JIS B 0401.
General tolerance in the dimensional outline drawing.
Unit : mm (approx.inch)
