IM 01E20D01-01E
7-1
7. PED (PRESSURE EQUIPMENT DIRECTIVE)
7. PED
(PRESSURE EQUIPMENT DIRECTIVE)
This chapter describes further requirements and notices
concerning the PED (Pressure Equipment Directive).
The description in this chapter is prior to other descrip-
tion in this User’s Manual.
(1) Technical Data
Module: H
Type of Equipment: Piping
Type of Fluid: Liquids and gas
Group of Fluid: 1 and 2
General-purpose Use / Submersible Type / Explosion
Proof Type
MODEL
DN
(mm) (*
1)
PS
(MPa) (*
1)
PS DN
(
MPa · mm)
CATEGORY(*
2)
AXF002G/C 2.5 4 10
Article 3, (*3)
paragraph 3
AXF005G/C 5 4 20
Article 3, (*3)
paragraph 3
AXF010G/C 10 4 40
Article 3, (*3)
paragraph 3
AXF015G/W/C 15 4 60
Article 3, (*3)
paragraph 3
AXF025G/W/C 25 4 100
Article 3, (*3)
paragraph 3
AXF032G/W/C
AXF040G/W/C
AXF050G/W/C
AXF065G/W/C
AXF080G/W/C
AXF100G/W/C
AXF125G/W/C
AXF150G/W/C
AXF200G/W/C
AXF250G/W/C
AXF300G/W/C
AXF350G/W/C
AXF400G/W/C
32
40
50
65
80
100
125
150
200
250
300
350
400
4
4
4
2
2
2
2
2
2
2
2
1
1
128
160
200
130
160
200
250
300
400
500
600
350
400
II
II
II
II
II
II
II
II
III
III
III
II
III
T0701.EPS
Sanitary Type
T0702.EPS
MODEL
DN
(mm) (*
1)
PS
(MPa) (*
1)
PS DN
(MPa · mm)
CATEGORY (*
2)
AXF015H 15 1 15
Article 3, (*3)
paragraph 3
AXF025H 25 1 25
Article 3, (*3)
paragraph 3
AXF032H
AXF040H
AXF050H
AXF065H
AXF080H
AXF100H
AXF125H
32
40
50
65
80
100
125
1
1
1
1
1
1
1
32
40
50
65
80
100
125
I
I
I
I
I
I
II
*1: PS: Maximum allowable pressure for Flowtube
DN: Nominal size
*2: For details, see “Table 6 covered by ANNEX II of EC
Directive on Pressure Equipment Directive 97/23/EC.”
*3: AXF002G/C to AXF025G/W/C, AXF015H and AXF025H
are outside the scope of CE marking of PED.
(2) Installation
WARNING
• Tighten the bolts of the piping joints according
to the prescribed torque values.
• Take measures to protect the flowmeters from
forces caused by vibration channeled through
the piping.
(3) Operation
WARNING
• The instrument should be operated with the
temperature and pressure of the fluid under
normal operating conditions.
• The ambient temperature should be that of
normal operating conditions.
• Take measures to prevent excessive pressure
such as water hammer, etc. To avoid water
hammer prevent the pressure from exceeding
the PS (maximum allowable pressure) by
setting the system’s safety valves, etc. appro-
priately.
• Should external fire occur, take safety mea-
sures at the device itself or system-wide
prevent it having an effect on the flowmeters.
• Avoid using fluids exceeding the corrosion
proof limitations of the lining and electrodes.
• Take measures not to abrade the metal pipe,
and avoid abrading the lining by using fluids
such as slurry and sand are contained.
To Next Page
