IM 01E20D01-01E
Edition Date Page Revised Item
8th Apr. 2007 1-2 (4) Changed the warning note of "Maintenance".
1-5 1.4 Added the ATEX documentation.
4-3, 4-10 4.3 Added the important note for the wiring ports.
4-4 (4) Added the important note for a 24 V power supply version (power
supply code 2).
2) Corrected the graph of "Supply Voltage and Cable Length".
5-1 5 Changed the warning note of "Maintenance".
5-7 5.4 Changed the warning note and important note of "Maintenance".
5.4.1 Changed the caution note of "Fuse Replacement".
Deleted the Figure 5.4.1.
5-7 to 5-8 5.4.2 Changed the content of section "Display Unit Replacement" to
"Changing the Direction of the Display Unit".
5-8 5.4.3 Deleted the section "Amplifier Replacement".
5-9 5.5 Added the important note for "Setting of Switches".
6-1 Deleted the "Communication Distance" and "Cable length
for Specific Applications" from item of "HART".
6-13 Changed the certificate number of TIIS.
6-15 Corrected the graph of "Supply Power and Cable Length for Power
Supply Code 2".
6-16 Corrected the value of span flow rate of size 32 mm.
6-17 Corrected the value of span flow rate of size 1.25 inch and size 36
inch.
6-28 Added the note to optional codes C1, C2, C3, EM, and G13.
6-29 Changed the gasket part number of manufacturer for optional code GC.
6-30 Changed the descriptive text of HF1.
6-31 Corrected the value of span flow rate of size 32 mm.
Added the note to optional codes C1, C2, C3, EM, and G13.
8-8 8.5 (1) Changed the certificate number of TIIS.
9th Jan. 2008 1-1 Added the postscript about PROFIBUS PA protocol type.
1-2 1.1 Added the warning note on "write protect".
4-3 4.1.4 (2) Added the postscript about PROFIBUS PA protocol type.
4-6 Added the postscript about PROFIBUS PA protocol type.
5-11 5.8.1 Changed the flow chart.
6-1 Added the postscript about PROFIBUS PA protocol type.
6-7 Corrected the frequency of "Input Impedance of Communicating
Device".
Changed the material of housing from "Carbon steel-JIS SPCC" to
"Carbon steel-JIS SPCC equivalent".
Corrected from "EN1.4404 equivalent" to "EN1.4401 equivalent" in
grounding ring of size 1100mm to 2600mm.
6-15 Added the CAUTION to "EMC Conformity Standard".
Changed the note of "Fluid Conductivity".
6-19 Changed the unit of "Vibration Conditions" from "G" to "m/s
2
".
6-21 to 6-32 Added the "-G" (PROFIBUS PA protocol).
Added the note of process connection code.
Added the note of calibration code C.
Added the applicable size for the electrode material code W.
6-33 to 6-36 Added the code F and G to item name.
Changed the value of mirror finished ceramics for optional code CM.
6-39 to 6-53 Added the code G.
