YOKOGAWA AXW Series Installation Manual

<4. Wiring>
43
IM 01E24A01-01EN
(3) Wiring of Remote Sensor and Remote
Transmitter
1) Connection with AXW4A Remote Transmitter
Connect wiring as shown in the gure below.
AXW4A transmitter
Remote sensor
AX01C dedicated
signal cable
EX2
EX1
A
B
C
Excitation cable
EX1
EX2
C
SA
SB
B
A
Non Explosion Protection Use
Explosion Protection Use
AXW4A transmitter
Remote sensor
AX01C dedicated
signal cable
Transmitter Remote sensor
EX2
EX1
A
B
C
SA
A
B
SB
C
EX1
EX2
Taping*
A
B
Taping*
C
EX1
EX2
* Individually tape and insulate the shields corresponding to SA and SB on the
remote sensor side.
Excitation cable
EX1
EX2
C
SA
SB
B
A
F0443.ai
Figure 4.5.3 Wiring Diagram (AXW4A Remote Transmitter)
2) Connection with AXG1A Remote Transmitter
Connect wiring as shown in the gure below.
AXG1A transmitter
Transmitter
Remote
sensor
F0444.ai
SA
A
B
SB
C
EX1
EX2
Taping*
A
B
Taping*
C
EX1
EX2
* Individually tape and insulate
the shields corresponding to
SA and SB on the remote
sensor side.
Remote sensor
EX2
EX1
A
B
C
AX01C dedicated
signal cable
Excitation
cable
Figure 4.5.4 Wiring Diagram (AXG1A Remote Transmitter)
3) Connection with AXFA11 Remote Transmitter
Connect wiring as shown in the gure below.
I+ I–
CURRENT OUT
AL+ AL– C SA AC B SB
ALARM OUT
N/– L/+
POWER SUPPLY
EX2EX1
EXCIT ATION
P– SI1+ SI2+ COMP+
PULSE OUT STATUS IN
SIGNAL
SO1+ COMSO2+
STATUS OUT
FUSE
2.5A 250V
AXFA11 transmitter
Transmitter
Remote
sensor
F0445.ai
SA
A
B
SB
C
EX1
EX2
Taping*
A
B
Taping*
C
EX1
EX2
* Individually tape and insulate
the shields corresponding to
SA and SB on the remote
sensor side.
Remote sensor
EX2
EX1
A
B
C
AX01C dedicated
signal cable
Excitation
cable
Figure 4.5.5 Wiring Diagram (AXFA11 Remote Transmitter)
