5-5
IM DL350-17EN
Status Reports
1
2
3
4
5
App
Index
5.4 Extended Event Register
The extended event register receives information about changes in the condition register, which
indicates the instrument’s internal condition. The information is the result of edge detection
performed by the transition filter.
Condition register
Transition filter
Extended event register
ACS0 PRN TST CAL TRG REC CAPNGOSCH 0 MESRUNKLKAN0
:STATus:CONDition?
0
14
15
1
6
7
5
4
38910
1112
13
2
0
14
15
1
6
7
5
4
38910
1112
13
2
0
14
15
1
6
7
5
4
38910
1112
13
2
67 5 4 3 2 189101112131415
16
:STATus:FILTer<x>
{RISE
|FALL|BOTH|NEVer}
:STATus:EESR?
FILTer<x>
The condition register bits are described below.
Bit 0 CAP (Capture) This bit is 1 when waveform acquisition is in progress.
Bit 1 REC (Record) This bit is 1 when recording is in progress.
Bit 2 TRG (Awaiting Trigger) This bit is 1 when the instrument is waiting for a trigger.
Bit 3 CAL (Calibration) This bit is 1 when calibration is in progress.
Bit 4 TST (Testing) This bit is 1 when a self-test is in progress.
Bit 5 PRN (Printing) This bit is 1 when the internal printer is operating or when data is
being transmitted to a network printer.
Bit 6 ACS (Accessing) This bit is 1 when a drive is being accessed.
Bit 7 MES (Measuring) This bit is 1 when automated measurement of waveform
parameters is in progress.
Bit 10 NGO (Go/No-Go) This bit is 1 when a GO/NO-GO search is in progress.
Bit 11 SCH (Search) This bit is 1 when a search is in progress.
Bit 12 RUN (Running) This bit is 1 when a measurement is in progress.
Bit 13 KLK (Keylock) This bit is 1 when the keys are locked.
Bit 14 AN (Analysis) This bit is 1 when an analysis is in progress.
The transition filter parameters detect changes in the specified condition register bits (numeric
suffixes 1 to 16) and overwrite the extended event register in the following ways.
RISE The specified extended event register bit is set to 1 when the corresponding condition register
bit changes from 0 to 1.
FALL The specified extended event register bit is set to 1 when the corresponding condition register
bit changes from 1 to 0.
BOTH The specified extended event register bit is set to 1 when the corresponding condition register
bit changes from 0 to 1 or from 1 to 0.
NEVer Always zero.
