4-109
IM DL350-17EN
Commands
1
2
3
4
5
App
Index
4.14 GONogo Group (Scope mode only)
The commands in this group deal with GO/NO-GO determination. You can make the same settings and the same
queries for settings and measured values that you can by using Analysis > GO/NO-GO in the top menu.
If the selectable range of the time axis is “<NRf> = –5 to 5div,” the selectable range varies depending on settings such
as the record length. For details, see “Notes about Cursor Measurement” in chapter 9 of IM DL350-01EN.
:GONogo:ACTion:IMAGe?
Function Queries all settings for the screen capture that is
saved when the execution condition is met.
Syntax
:GONogo:ACTion:IMAGe?
:GONogo:ACTion:IMAGe[:MODE]
Function Sets or queries whether a screen capture is
saved when the execution condition is met.
Syntax
:GONogo:ACTion:
IMAGe[:MODE] {<Boolean>}
:GONogo:ACTion:IMAGe:MODE?
Example
:GONOGO:ACTION:IMAGE:MODE ON
:GONOGO:ACTION:IMAGE:MODE?
-> :GONOGO:ACTION:IMAGE:MODE 1
:GONogo:ACTion:IMAGe:CDIRectory
Function Sets the current directory where the screen
capture is saved to when the execution condition
is met.
Syntax
:GONogo:ACTion:IMAGe:
CDIRectory {<String>}
:GONogo:ACTion:IMAGe:CDIRectory?
<String> = Up to 16 characters
Example
:GONOGO:ACTION:IMAGE:
CDIRECTORY "CASE1"
:GONOGO:ACTION:IMAGE:CDIRECTORY?
-> :GONOGO:ACTION:IMAGE:
CDIRECTORY "CASE1"
:GONogo:ACTion:IMAGe:DRIVe
Function Sets or queries the medium that the screen
capture is saved to when the execution condition
is met.
Syntax
:GONogo:ACTion:IMAGe:DRIVe {NETWork|
SD|USB,<NRf>}
:GONogo:ACTion:IMAGe:DRIVe?
<NRf> = 1, 2
Example
:GONOGO:ACTION:IMAGE:DRIVE USB
:GONOGO:ACTION:IMAGE:DRIVE?
-> :GONOGO:ACTION:IMAGE:DRIVE USB,0
Description Specify NETWork for a network drive.
Specify SD for the SD memory card.
Specify USB for a USB storage medium.
:GONogo?
Function Queries all GO/NO-GO determination settings.
Syntax
:GONogo?
:GONogo:ACONdition
Function Sets or queries the GO/NO-GO determination-
action condition.
Syntax
:GONogo:ACONdition {ALWays|FAILure|
SUCCess}
:GONogo:ACONdition?
Example
:GONOGO:ACONDITION ALWAYS
:GONOGO:ACONDITION?
-> :GONOGO:ACONDITION ALWAYS
:GONogo:ACTion?
Function Queries all settings for the action that is
performed when the execution condition is met
and the settings for the condition itself.
Syntax
:GONogo:ACTion?
:GONogo:ACTion:BUZZer
Function Sets or queries whether a beep is sounded when
the execution condition is met.
Syntax
:GONogo:ACTion:BUZZer {<Boolean>}
:GONogo:ACTion:BUZZer?
Example
:GONOGO:ACTION:BUZZER ON
:GONOGO:ACTION:BUZZER?
-> :GONOGO:ACTION:BUZZER 1
:GONogo:ACTion:FOLDer
Function Sets or queries whether a date folder is created
when waveform data or screen capture data is
saved to the storage medium when the execution
condition is met.
Syntax
:GONogo:ACTion:FOLDer {<Boolean>}
Example
:GONOGO:ACTION:FOLDER ON
:GONOGO:ACTION:FOLDER?
-> :GONOGO:ACTION:FOLDER 1
