4-1
IM DL350E-17EN
Commands
4
Chapter 4 Commands
4.1 List of Commands
Command Function page
ACQuire Group
:ACQuire?
Queries all waveform acquisition settings. 4-30
:ACQuire:AVERage?
Queries all averaging settings. 4-30
:ACQuire:AVERage:COUNt
Sets or queries the number of waveform acquisitions to perform during
averaging.
4-30
:ACQuire:AVERage:EWEight
(Exponent Weight)
Sets or queries the attenuation constant of exponential averaging. 4-30
:ACQuire:COUNt
Sets or queries the number of waveform acquisitions to perform for repetitive
measurement in scope mode.
4-30
:ACQuire:MODE
Sets or queries the waveform acquisition mode. 4-30
:ACQuire:PROTate
Sets or queries the pulse/rotate setting to use during external clock input. 4-30
:ACQuire:RECorder?
Queries all acquisition settings for recorder mode. 4-30
:ACQuire:RECorder:CONDition
Sets or queries the acquisition conditions for recorder mode. 4-30
:ACQuire:RECorder:NUMeric?
Queries all SD numeric recording settings for recorder mode. 4-31
:ACQuire:RECorder:NUMeric:INTer
val
Sets or queries the recording interval of SD numeric recording for recorder
mode.
4-31
:ACQuire:RECorder:NUMeric:MODE
Sets or queries the ON/OFF state of SD numeric recording for recorder
mode.
4-31
:ACQuire:RECorder:RLENgth
Sets or queries the external sampling recording length for recorder mode. 4-31
:ACQuire:RECorder:SINTerval
(Sampling Interval)
Sets or queries the sampling interval for recorder mode. 4-31
:ACQuire:RECorder:TIME
Sets or queries the record time for recorder mode. 4-31
:ACQuire:RLENgth
Sets or queries the record length for scope mode. 4-31
:ACQuire:RTOut?
Queries all SD recording settings. 4-32
:ACQuire:RTOut:ANAMing
Sets or queries the SD-recording auto naming feature. 4-32
:ACQuire:RTOut:COMMent
Sets or queries the SD recording comment. 4-32
:ACQuire:RTOut:DIVide:MODE
Sets or queries whether divided recording is enabled for SD recording. 4-32
:ACQuire:RTOut:DIVide:NUMBer
Sets or queries the number of divisions when divided recording is performed
during SD recording.
4-32
:ACQuire:RTOut:FILename
Sets or queries the SD-recording file name. 4-32
:ACQuire:RTOut:MODE
Sets or queries whether SD recording will be performed. 4-32
:ACQuire:SMODe (System Mode)
Sets or queries the system mode (recorder mode or scope mode). 4-32
ANALysis Group
:ANALysis:HARMonic?
Queries all harmonic analysis settings. 4-33
:ANALysis:HARMonic:FREQuency
(Frequency)
Sets or queries the frequency to be analyzed in harmonic analysis. 4-33
:ANALysis:HARMonic:GRAPh?
Queries all settings related to the harmonic analysis result display. 4-33
:ANALysis:HARMonic:GRAPh:DEGRee
Sets or queries the harmonic display mode of harmonic analysis. 4-33
:ANALysis:HARMonic:GRAPh:DITem?
Sets or queries the displayed items of harmonic analysis results. 4-33
:ANALysis:HARMonic:GRAPh:LSTart
Sets or queries the starting harmonic to be displayed in the harmonic
analysis display list of harmonic analysis.
4-33
:ANALysis:HARMonic:GRAPh:MODE
Sets or queries the type of harmonic analysis result display. 4-33
:ANALysis:HARMonic:GRAPh:PSCale
Sets or queries the phase angle scale of the harmonic analysis result display. 4-33
:ANALysis:HARMonic:GRAPh:SCALe
Sets or queries the vertical scale when the harmonic analysis result display
is set to Bar.
4-33
:ANALysis:HARMonic:LRMS<x>?
Queries all harmonic RMS analysis settings. 4-34
:ANALysis:HARMonic:LRMS<x>:HYST
eresis
Sets or queries the frequency detection hysteresis of harmonic RMS
analysis.
4-34
:ANALysis:HARMonic:LRMS<x>:MODE
Sets or queries the computation mode of harmonic RMS analysis. 4-34
:ANALysis:HARMonic:LRMS<x>:RESu
lt?
Queries all analysis results related to harmonic RMS analysis. 4-34
:ANALysis:HARMonic:LRMS<x>:RESu
lt:FREQuency?
Queries the fundamental frequency of harmonic RMS analysis. 4-34
:ANALysis:HARMonic:LRMS<x1>:RES
ult:PHIK<x2>?
Queries the phase angle of each harmonic of harmonic RMS analysis. 4-34
